W9725G6IB
9.7
Capacitance
SYM.
C CK
C DCK
C I
C DI
C IO
C DIO
PARAMETER
Input Capacitance , CLK and CLK
Input Capacitance delta , CLK and CLK
input Capacitance, all other input-only pins
Input Capacitance delta, all other input-only pins
Input/output Capacitance, DQ, LDM, UDM, LDQS,
LDQS , UDQS, UDQS
Input/output Capacitance delta, DQ, LDM, UDM,
LDQS, LDQS , UDQS, UDQS
MIN.
1.0
?
1.0
?
2.5
?
MAX.
2.0
0.25
1.75
0.25
3.5
0.5
UNIT
pF
pF
pF
pF
pF
pF
9.8
Leakage and Output Buffer Characteristics
SYM.
I IL
I OL
V OH
V OL
I OH(dc)
I OL(dc)
PARAMETER
Input Leakage Current
(0V ≦ V IN ≦ V DD )
Output Leakage Current
(Output disabled, 0V ≦ V OUT ≦ V DDQ )
Minimum Required Output Pull-up
Maximum Required Output Pull-down
Output Minimum Source DC Current
Output Minimum Sink DC Current
MIN.
-2
-5
V TT + 0.603
?
-13.4
13.4
MAX.
2
5
?
V TT - 0.603
?
?
UNIT
μA
μA
V
V
mA
mA
NOTES
1
2
3, 5
4, 5
Notes:
1. All other pins not under test = 0 V.
2. DQ, LDQS, LDQS , UDQS, UDQS are disabled and ODT is turned off.
3. V DDQ = 1.7 V; V OUT = 1.42 V. (V OUT - V DDQ )/I OH must be less than 21 ? for values of V OUT between V DDQ and V DDQ -
0.28V.
4. V DDQ = 1.7 V; V OUT = 0.28V. V OUT /I OL must be less than 21 ? for values of V OUT between 0 V and 0.28V.
5. The values of I OH(dc) and IOL(dc) are based on the conditions given in Notes 3 and 4. They are used to test drive current
capability to ensure V IH min plus a noise margin and V IL max minus a noise margin are delivered to an SSTL_18 receiver.
Publication Release Date: Oct. 23, 2009
- 39 -
Revision A04
